Haier Pinnacle 3.5kW/3.7kW Split Reverse Inverter Air Conditioner

Haier Pinnacle 3.5kW/3.7kW Split Reverse Inverter Air Conditioner

Model:

AS35PBDHRA-SET

Ipn:

825672

1 4
Haier
Save 15%
Haier Pinnacle 3.5kW/3.7kW Split Reverse Inverter Air Conditioner

Haier Pinnacle 3.5kW/3.7kW Split Reverse Inverter Air Conditioner

Model:

AS35PBDHRA-SET

Ipn:

825672

$929.00
Was $1,099.00 $929.00
Taxes included.
View full details
You have not set a location
Overview
Delivery & Returns
Payment Options
Back up plans

Overview

description

The Haier Pinnacle 3.5kW/3.7kW Split Reverse Inverter Air Conditioner combines smart home integration with advanced air purification and powerful performance. Ready to use straight out of the box, it features built-in Wi-Fi and voice control compatibility with Google and Alexa. Offering 3.5kW cooling and 3.7kW heating, it delivers dependable comfort supported by energy-efficient inverter technology. UV sterilisation helps reduce airborne bacteria and viruses, while indoor and outdoor self-cleaning functions promote long-term hygiene and efficiency. An extended 18-metre air throw evenly distributes airflow, and Turbo Cool mode delivers rapid cooling when needed. Ideal for modern homes, this system provides intelligent control, cleaner air and reliable climate performance.

specifications

  • Brand
    Haier
  • IPN
    825672
  • Model
    AS35PBDHRA-SET
  • Manufacturer's Warranty
    5 Years
  • Size
    3.5/3.7kW
  • Width
    805 mm
  • Height
    292 mm
  • Depth
    200 mm
  • Cooling capacity (kW)
    3.5kW
  • Heating capacity (kW)
    3.7kW
  • COP
    3.70
  • EER
    3.80
  • HSPF-RES (Hot/Average/Cold)
    4.816 / 4.046 / 3.452
  • HSPFCOM (Hot/Average/Cold)
    4.841 / 4.379 / 3.844
  • Star-Cool (Hot/Average/Cold)
    3.5 / 3.5 / 3.5
  • Star-Heat (Hot/Average/Cold)
    3.0 / 2.5 / 1.5
  • TCSPF-COM (Hot/Average/Cold)
    5.941 / 6.105 / 6.561
  • TCSPF-RES (Hot/Average/Cold)
    5.494 / 5.053 / 5.268
  • 24 Hour timer
    Yes
  • 56°C Steri-clean
    Yes
  • Anti-bacterial silver ion coating
    Yes
  • Auto restart
    Yes
  • Auto swing-up and down
    Yes
  • Blue fin coils
    Yes
  • Built-in Wi-Fi smart control
    Yes
  • Concealed LED display
    Yes
  • DC inverter
    Yes
  • DRED (Demand Response) ready
    Yes
  • Dry mode
    Yes
  • Intelligent air
    Yes
  • Internal and external heat exchanger self-cleaning
    Yes
  • Long distance air supply
    12
  • MEPS approved
    Yes
  • Refrigerant factory charge
    0.84
  • Self diagnostics
    Yes
  • Standard controller
    wireless
  • UV Protect
    UVC sterilisation
  • Voice control via Google Home or Amazon Alexa
    Yes
  • Indoor unit model
    AS35PBDHRA
  • Liquid line
    Pipe size 6.35
  • Maximum pipe run
    15
  • Outdoor unit model
    1U35MADFRA
  • Suction line
    Pipe size 9.52
  • DC inverter
    Yes
  • R32 Refrigerant
    Yes
  • Sound power SWL (outdoor)
    63dBA
  • Sound pressure SPL (indoor)
    40 / 36 / 32 / 22dBA
  • Sound pressure SPL (outdoor)
    53dBA
  • Power phase
    1.0
  • Supply frequency
    50Hz
  • Supply voltage
    230V

features

  • UV Protect to kill bacteria & viruses
  • Healthier air
  • Voice and remote control
  • Air flow to every corner
  • Easy installation and maintenance
  • Sleep mode
  • Turbo mode
